Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: TKBHOME
  • Model Number: TZ68E
  • Operating Temperature: 0-40
  • Max. Current: 15
  • Max. Voltage: 230V
  • Sample time: Within 5days after receive payment
  • Shipping: EMS,TNT,DHL,China postal packet
  • Power rating: 230V, 50 Hz
  • Z-Wave type: Slave
  • Distance: 30 m line of sight
  • Display: LED inside push button
  • Local interaction: One button for switching, inclusion, exclusion and association
  • Voltage: 230VAC, 50Hz
  • Operation range: Up to 100 feet
  • LED for indicaton: Very low electricity consumption

Packaging & Delivery

Packaging Details In white box ( 10.4x9.7x6.7 cm )
Delivery Time 5 days to Europe

Smart Z-Wave Plug In Switch With Power Meter




1.TZ68 G/E/F


  • Power rating: 230V, 50 Hz
  • Maximum load: up to 15 A(Germany/France) ,13A (UK)
  • Wireless behaviour: transmitter
  • Z-Wave type: slave
  • Distance: up to 100 m outdoor, up to 30 m in buildings
  • Display:  LED inside push button
  • Local interaction: one button for switching, inclusion, exclusion and association


The TZ68 is a switch plug-in and is used between a standard wall outlet and lamps connected to a wall outlet by cable. The unit is able to carry out inclusion,exclusion or association in a z-wave network by a remote controller, PC software or any other kind of z-wave controller .It switches all kind of loads.Local operation is possible by pressing the button on the device.


2.TZ88  G/F/E


This plug-in ON/OFF switch is able to detect current wattage (5~3150W) and overload wattage (3010~3300W) of connected lights or appliances. When detecting overload state, the Switch will be disabled and its On/Off button will be lockout of which LED will flash quickly. However, unplug and re-connect the switch will reset its overload condition to normal status.





Technical Data:

  • Frequency: 868.42MHz
  • Maximum load: 300W ,for incandescent lamps only
  • Wireless behaviour: receiver
  • Fluorescent light: No
  • Power supply: Via 230 V power
  • Dimension : Approximately. 10.2 x6x 5.6cm (mounted in wall receptacle)

Outlet plug

Electrical switches and dimmers control electrical loads in general, and lamps in particular. Electrical switches typically switch all kinds of loads but the application of dimmers is restricted to lamps. Depending on the dimmer method only resistive incandescent or a broader range of inductive and reactive loads are dimmable. Wall outlet plug-in devices are installed very easily without any further electric knowledge by just plugging them into the wall outlet. Wall plug-in devices receive Z-Wave signals from controllers and switch their load accordingly.



What is z-wave ?

Z-Wave is a wireless technology that makes regular household products, like lights, door locks and thermostats "smart". Z-Wave products "talk" to each other wirelessly and securely and can be accessed and controlled on your phone, tablet or pc.

By using a Z-Wave gateway you can connect to the things inside your house whether you're at home or while you're away. Currently there are nearly 1000 different Z-Wave products that all work together so you can choose the products that are right for your home.


Z-Wave puts the power of home control and monitoring in the palm of your hand… literally. With your smart phone, tablet or PC you can control and access your Z-Wave devices at home. This means you get

  • Peace of mind knowing your home is secure — no matter where you are
  • More money in your pocket by saving energy easily — with no sacrifice
  • Convenience like you've never known — one button to "shut down" your home when you leave
  • Security knowing you'll receive an alert if there is any trouble at home — water, fire, alarm, door/window sensors
About us

TKB CONTROL SYSTEM LIMITED is an ISO9001:2008 approved hi-tech enterprise. We specialize in design, development, manufacture and marketing high-end intelligent control system and related products for smart homes

We has pushed out Z-Wave Smart Home Products,Thermostats, Remote Control Socket, Central Vacuum System, Central Ventilator, Circuit Breakers and Ground Socket to the international market by the investigation of electrical science and technology trend in the international market. At the same time; we carry out import and export business in home automation system equipment and so on.

With the aim of "quality first, customer interests first", our products have got TUV, GS, CE, RoHS, R&TTE and Z-Wave certification. Our mission is to be an international brand-name enterprise. Developing and leaping with customers together is TKB's beautiful future.
